Figures in which the part appears:
Also known as:
208901, 0208901, 00208901
208901, 0208901, 00208901
PISTON - Part 208901 for Terex cranes
Fits these models: Demag AC, Terex RT 500-1
Figure 3.4:
| Pos nr | Part number | Description | Weight in kg |
|---|---|---|---|
| 208910 | SET | ||
| 7096531 | CYLINDER, EXTEND | ||
| 1 | 201123 | LOCKNUT | |
| 2 | 208900 | SEAL, PISTON | |
| 3 | 208901 | PISTON | |
| 4 | 207126 | CONTROL ROD ASSY | 0.004 |
| 5 | 211591 | ROD | |
| 6 | 208903 | HEAD | |
| 7 | 208904 | 0-RING | |
| 8 | 208905 | BACK-UP | |
| 9 | 211592 | BARREL | |
| 10 | 208907 | LOCKWIRE | |
| 11 | 208908 | WIPER | |
| 12 | 208909 | SEAL, ROD |
* Selected parts are automatically added to your RFQ list *
