Search for Crane Part number

(click on image to open PDF document)

Figures in which the part appears:
2228097-ETL (Krupp KMK 4070 )
Also known as:
2228098, 02228098, 002228098

SWING-AWAY BOOM EXTENSION 10/16 M - Part 2228098 for Krupp cranes

Fits these models: Krupp KMK 4070

Figure 2228097-ETL:
