Grove 1922304

Search for Crane Part number

(click on image to open PDF document)

Figures in which the part appears:

Also known as:
1922304, 01922304, 001922304

Parts for Grove GMK 5220, Figure 3064352-ETL:
Part Number 1922304: HOOD

Pos nr	Part number	Description	Weight in kg
1	3066565	SIGN AND SYMBOLS
8	1673394	TOOLS	15
9	3056223	SIGN, (VSET= 85 KM/H)	0.001
10	3008156	SIDE MARKER LAMP MOUNTING
10.01	2310591	REFLECTOR
10.02	1068274	PENDULUM
11	0551126	EXTENSION LADDER (2,25 M - 3,9	18
13	2214622	ROPE SLING
14	0435783	SHACKLE	0.36
17	2222078	OIL FILLER HOSE (FOR SUSPENSION CYLINDER)	0.295
17.01	1205137	HOSE	0.24
21	0933227	TOOL BOX COMPLETE	7.600
22	3008571	COUPLING PIN	1
23	3041105	SPECIAL TOOLS (FOR LUBRICATION HOSES)	0.130
24	3012981	HOSE	0.001
24.01	2313532	FIR-G-PLUG	0.180
24.02	2313536	DUST CAP RED	3
24.03	3317211	HOSE
24.04	3316689	FIR-G-SOCKET
24.05	3317210	DUST CAP FOR SOCKET
27	3011251	RADIATOR GRILLE TAIL PIECE	4.220
28	3011254	PROTECTION COVER	5.130
33	3066566	ACCESSORY SUPPLI ES, EXPENDABLE MATERIAL
34	1670611	ROTARY BEACON	1.060
34.01.01	1576840	GLASS FOR LAMP	0.310
34.01.02	1576839	SEAL
34.01.03	0438912	BULB (H1, 24 V, 70 W)	0.015
34.01.04	1922304	HOOD	2
35	3057150	BOLT FOR EMERGENCY MODE	0.800
35.01	3317793	PIN	0.12
36	2312493	WORKING LIGHT	1.020
36.01	2316460	BULB (8GH 002090-251)	0.01
36.02	2316461	REFLECTOR	1
