Grove 1925722 - PIN (NO HOLES) 5.000 DIA X 8.25 LG

Pos nr	Part number	Description	Weight in kg
2	2309017	GEAR REDUCER HOUSING
3	0100517	STRAIGHT PIN
4	2309018	SHAFT SEAL	0.001
5	2309053	SHAFT SEAL	0.001
6	1927169	HOUSING COVER
8	1925739	BEARING FLANGE
9	1684580	GROOVED BALL BEARING	0.780
11	1684138	CIRCLIP	0.018
12	2309054	O-RING, 120 X 3	0.005
13	1925740	GEAR WHEEL	4.98
14	1925741	GEAR WHEEL	10.1
15	2309025	AXLE CASING
16	1925785	SCREW PLUG	0.08
17	0117151	SEALING RING	0.005
18	1371216	SCREW PLUG	0.23
19	1371208	SEALING RING	0.005
20	0117131	RING SEALING	0.001
21	1925788	AIR BLEEDER	0.05
23	2309022	COVER	10.26
25	1069223	O-RING	0.1
26	2309020	FLANGE
28	2309031	DIFFERENTIAL HOUSING	10.700
29	1925722	PIN (NO HOLES) 5.000 DIA X 8.25 LG	20.684
30	1925723	THRUST WASHER	0.070
31	1925724	DIFFERENTIAL SIDE GEAR	0.9
32	1925725	DIFFERENTIAL BEVEL GEAR	0.66
33	1925726	DIFFERENTIAL SPIDER	1.372
34	1925727	BEARING BUSH	0.075
35	1925349	TAPERED ROLLER BEARING	1.37
36	2309029	ADJUSTING RING	0.730
40	1684143	HEXAGON SCREW	0.06
41	1925729	BEARING BUSH	0.02
42	2309032	SLIDING SLEEVE	0.62
43	2309033	SHIFT FORK
44	2309034	PISTON	0.13
45	2309035	BACK-UP WASHER	0.010
46	2212311	O-RING, 32 X 5	0.005
47	2309037	THREADED BUSH	0.090
48	1925786	PRESSURE SPRING	0.03
49	2309038	O-RING, 50 X 3	0.005
50	2309039	CYLINDER	0.26
51	1684575	PRESSURE SWITCH	0.300
52	0177137	GASKET
53	1925746	PINION AND RING GEAR	17.370
54	0433890	BEARING	0.001
55	1925790	BACK-UP WASHER	0.17
56	0434651	TAPERED ROLLER BEARING	2
57	1925748	SPACER RING
58	1684119	DRIVE-IN NUT	0.420
59	2257799	DRIVE FLANGE	3.180
60	1925750	DRIVE-IN NUT	0.22
61	2257786	HEXAGON SCREW	0.08
62	2309049	SHAFT	5.72
63	2309050	SHAFT	5.72
64	0434575	GROOVED BALL BEARING	1.085
65	2252487	BACK-UP WASHER	0.06
66	1207981	CIRCLIP
67	2309048	ROTARY SHAFT SEAL	0.055
70	2309043	PRESSURE SPRING	0.03
71	2309047	CIRCLIP
73	2309051	RING
76	0011713	GASKET
77	2309045	SHIM RING	0.001
78	2309044	BUSH
79	2309046	ROD	1.100
82	2309023	O-RING, 108 X 3	0.005
85	2257800	TRANSFER DRIVE SHAFT
88	2309021	O-RING, 265 X 4	0.025
89	2309036	ROD	0.29
90	1925719	COVER
92	1925758	ADJUSTING RING	0.620
93	1925759	LOCKING PLATE
95	1684139	BACK-UP WASHER
97	0028503	CIRCLIP	0.095
98	0434649	TAPERED ROLLER BEARING	1.31
