Parts for Grove GMK 4090-1, Figure 3114750-ETL:
Part Number 3090467: SLIDER

Pos nr	Part number	Description	Weight in kg
1	1677153	CYLINDRICAL ROLLER BEARING	2.140
1	3084957	ROPE PULLEY, ASSEMBLY	5.200
1	3084958	PULLEY	3.880
2	3084959	AXLE FOR HEAD SHEAVES
3	1684770	PIN	1.580
4	1065255	SPACER RING	0.07
5	1065128	SPACER RING	0.2
6	3084965	ROPE-PROTECTION HOLDER	0.865
7	3055577	PIN	0.385
8	0438773	SAFETY LINCH PIN	0.165
9	1067552	RETAINING PIN	0.16
16	0554999	SPACER RING	0.45
17	3321291	SPACER RING	0.67
20	2312969	SPACER RING	0.100
21	1370032	SPACER RING	1
22	2304349	LIFTING LIMIT SWITCH, WEIGHT	6.750
22	2312366	WEIGHT 2
22	2312367	WEIGHT 1
22	2312370	STOP BOLT	0.28
22	3041355	WIRE ROPE SLING	0.280
23	3007472	SHACKLE	0.7
24	3126827	HOLDER	1.260
28	3092397	HOLDER (ANEMOMETER)	0.401
32	3080669	SLIDER	1.24
33	3323869	PRESSURE SPRING	0.335
33	3115234	LOCKING DEVICE
33	3115238	GUIDE TUBE
33	3115239	LOCKING PIN
35	3115197	CONNECTING LINK	0.94
37	3115341	CONNECTING LINK	1.73
41	3090467	SLIDER	0.220
43	3080679	SLIDER	0.085
44	3115369	SLIDER	0.1
46	3317550	GUIDE PIN L=25, T=5	0.015
47	3317551	GUIDE PIN L=25, T=6	0.01
48	3317552	GUIDE PIN L=27, T=7	0.02
49	3317553	GUIDE PIN L=28, T=8	0.02
50	3317554	GUIDE PIN L=29, T=9	0.02
51	3317555	GUIDE PIN L=30, T=10
55	2251403	EXTENSION PIECE	0.01
56	2311780	ANGLE MALE COUPLING	0.140
60	3115365	LUBRICANT HOSE	0.09
