Grove 2227108 - LEVER 1

Search for Crane Part number

(click on image to open PDF document)

Figures in which the part appears:

3054050-ETL (Grove GMK 4075 )
3053986-ETL (Grove GMK 4080-1 )
3053986-ETL (Grove GMK 4100-L UNLOCKING STEERING)
3053986-ETL (Grove GMK 5095 )
3054050-ETL (Grove GMK 5100 )
2219949-ETL (Grove GMK 5160 )
2225346-ETL (Grove GMK 5180 )
2225346-ETL (Grove GMK 5200 )
2219949-ETL (Krupp KMK 4070 )
2225346-ETL (Krupp KMK 4080 )
2219949-ETL (Krupp KMK 5120 )

Also known as:
2227108, 02227108, 002227108

Parts for Krupp KMK 4080, Figure 2225346-ETL:
Part Number 2227108: LEVER 1

Pos nr	Part number	Description	Weight in kg
	1926217	REVERSE DRIVING LAMP SWITCH	0.001
	2253542	CONTROL SWITCH	0.501
1	2227108	LEVER 1	16.5
2	2227103	LEVER 2	17.500
3	2227110	LEVER 3	19
4	2254225	CENTERING RING	6.070
5	2254223	STEEL PLATE	0.8
6	2254222	RING	0.28
7	2215541	HEXAGON BOLT	0.240
8	2253245	THRUST WASHER	0.080
13	2253244	PERMAGLIDE BUSH	0.500
14	2227114	FLANGE
15	2254224	RING	1.63
21	2253243	BUSH	0.37
22	0026244	THREADED PIN , 6
23	2254331	SPIRAL CLAMP	0.040
24	2254330	BELLOWS	1.1
27	2215543	SEAL	0.16
36	1682057	HIGH PRESSURE PIPE

* Selected parts are automatically added to your RFQ list *

2227108 Grove GMK 4100-L LEVER 1
