Grove 2311070 - REPAIR KIT

Search for Crane Part number

(click on image to open PDF document)

Figures in which the part appears:

3053037-ETL (Grove GMK 2035 ATTACHMENT, SLIDE PLATES)
2228286-ETL (Grove GMK 3050 CRANE OPERATOR)
3078484-ETL (Grove GMK 3050 V3 )
3053037-ETL (Grove GMK 3050-1 ATTACHMENT SLIDERS)
3053037-ETL (Grove GMK 3055 )
3095396-ETL (Grove GMK 4080-1 )
3056101-ETL (Grove GMK 5100 )
3056743-ETL (Grove GMK 5100 )
3056101-ETL (Grove GMK 5170 )
3009910-ETL (Grove GMK 5180 )
3056101-ETL (Grove GMK 5200 )
3057852-ETL (Grove GMK 5200 )
3056101-ETL (Grove GMK 5220 )
3056101-ETL (Grove GMK 6220L )
3057852-ETL (Grove GMK 6220L )
3008942-ETL (Grove GMK 6300 )

Also known as:
2311070, 02311070, 002311070

Parts for Grove GMK 3050, Figure 2228286-ETL:
Part Number 2311070: REPAIR KIT

Pos nr	Part number	Description	Weight in kg
001	2228288	CRANE OPERATOR
4	1678463	CLAMPING STRIP (YARD GOOD)	0.5
5	0552253	FILLER-PROFILE STRIP (YARD GOO	0.055
6	2305256	FRONT DOOR	4.1
6	0680592	RIVET NUT
7	2311061	PROFILED SEAL (METER WARE)	0.19
13	2311056	SIDE PANE	0.001
15	2311062	FASTENER	0.32
16	2311070	REPAIR KIT	0.740
16	2311058	DACHSCHEIBE	59
17	2311063	CLAMPING STRIP (METER WARE)	0.65
36	2311057	SIDE PANE	25.500
44	2212494	COVER MOUNTING RECE	0.82
52	2311086	HINGE
65	1374656	HEXAGON SOCKET HEAD CAP SCREW	0.011
66	1923997	HEXAGON NUT M5	0.1
67	1923999	WASHER M5	0.1
68	2212983	COUNTERSUNK SCREW M6X20	0.45
69	1146988	HEXAGON SCREW

* Selected parts are automatically added to your RFQ list *

2311070 Grove GMK 4080-1 REPAIR KIT
