3324900-ETL (Grove GMK 4080-1 )
GMK 5220-2 (Grove GMK 5220-2 )

Also known as:
3324945, 03324945, 003324945

Parts for Grove GMK 4080-1, Figure 3324900-ETL:
Part Number 3324945: TENSION SPRING WITH RELEASE

Pos nr	Part number	Description	Weight in kg
1	3324826	COVER	0.600
1	3324911	HEADREST
2	3324912	SEAT, UPPER PART	10
2	3324935	COVERING FOR BACK-REST	0.390
2	3324936	COVERING FOR SEAT	0.266
2	3326685	SEAT CONTROL SWITCH	0.22
3	3324913	COVERING, LEFT
4	3324914	COVERING, RIGHT
5	3324915	HAND WHEEL
6	3324916	LONGITUDINAL ADJUSTMENT	0.001
7	3324937	BELLOWS
7	3324938	GAS-SPRING	0.001
7	3324939	BOWDEN CABLE	0.2
7	3324940	AXLE FOR GAS SPRING	0.48
7	3324941	HANDLE
7	3324942	ROLL BUSH	0.005
7	3326440	HEIGHT CONTROL	0.001
8	3324918	LONGITUDINAL ADJUSTMENT
9	3324945	TENSION SPRING WITH RELEASE	1.43
9	3326430	CONSOLE HOUSING
9	3326431	ARMREST	0.25
9	3326441	CONSOLE WITH ARMREST (ANTHRACITE), RIGHT
10	3326432	CONSOLE HOUSING
10	3326442	CONSOLE WITH ARMREST (ANTHRACITE), LEFT	2.150
11	3326433	CONSOLE HOUSING	0.001
11	3326443	CONSOLE WITH ARMREST (LIGHT GRAY), RIGHT
12	3326434	CONSOLE HOUSING
12	3326444	CONSOLE WITH ARMREST (LIGHT GRAY), LEFT	3.200
