Search for Crane Part number

(click on image to open PDF document)

Figures in which the part appears:
AT part (Grove )
2170100200 (Grove AT 750 BE )
2170700035 (Grove AT 750 BE )
Also known as:
7872000501, 07872000501, 007872000501
Parts for Grove AT 750 BE, Figure 2170700035:
Part Number 7872000501: INDUCTIVE PROXI
Pos nr Part number Description Weight in kg
1 2170700033 AXLE ASSY
2 2170700034 AXLE ASSY
4 7601000383 VERTICAL SOCKET DRAG LINK ASSY
5 6810002155 RELAY SHAFT
6 2170700037 ARM RELAY
7 6705012943 PLATE
8 7949000235 WASHER 1/2 ID 0.006
9 6705012656 SHIM
10 6443000961 CAP PIPE
11 7009000041 BRAKE CHAP$BER ASSEPIBLY
12 7950200050 WASHER HELICAL 0.011
13 7950200161 WASHER 0.030
14 7660200030 HEX NUT
15 4170700002 PIN, LOCK
16 7872000666 INDUCTIVE PROXI
17 7768002470 TORGUE ROD ASSEMBLY
18 7768002469 TORGUE ROD ASSEPIBLY
19 7127263050 BOLT
20 7949000236 WASHER 0.027
21 7661260005 18 MM DIA NORM.
22 6372003583 CVLINER ASSEPIBLY
23 6689000930 RETAINING PI
24 6199001916 BUSHING
25 7690184810 COTTER PIN
26 7115171250 CAP SCREW
27 7949000317 WASHER I.D. 0.082
28 6978000877 WIRE, SAFETY
29 2170100112 BLOCK
30 7112151250 CAPSCREW
31 7950150050 LOCK WASHER 5116" RED 0.002
32 7444000300 FITTING
33 6768002345 ROD-.375" DIA
34 7660161600 LOCKNUT, HEX
35 4170100249 PLATE
36 7660300230 JAMNUT
37 7872000667 INDUCTIVE PROXIMITY SENSOR
38 7638000219 MOUTH, CENTER
39 6949000588 WASHER
40 6949000589 WASHER
41 6208080809 BUSHING
42 7110182423 CAPSCREW
43 7660181603 LOCKNUT, HEX
44 7638000217 SUSPENSION C
45 7099000574 CAPSCREW
46 7659000270 NUT 0.136
47 6099000584 SAFETY WIRE BOLT
48 7127273050 HHCS M20X140 -10,9 ISO 4014
49 7661270005 NUT HEX HD 0.05
50 7127273650 BOLT, HEX
51 6372003582 CYLINDER ASSENSLY -
52 7601000382 DRAG LINK ASSY
53 7949000237 WASHER 7/8" I.D. 0.503
54 7872000481 INDUCTIVE PROX. SENSOR
55 7872000501 INDUCTIVE PROXI 1
56 6030002978 ANGLE
57 6030002952 ANGLE
58 7112140550 CAP SCREW,1/4" -20 N. C. X 5/8"
59 7950140050 LOCK WASHER 0.006
60 7950140141 WASHERI/IT" HARROW 0.050
61 7949000259 WASHER 0.100
101 9049107950 AXLE ASSEMBLV -
102 6372003383 CYLINDER ASSEPIBLY STEER
103 7826000016 BALL JOINT 2.976
104 7690053210 PIN, COTTER
110 6199001974 BUSHING
112 7127242653 CAP SCREW, M16X100 HEX HEAD
113 7661240003 NUT, HEX 0.030
201 9049107951 AXLE ASSEPIBLY
208 6199001972 BUSHING
