Grove 9904101418

Search for Crane Part number

(click on image to open PDF document)

Figures in which the part appears:

Also known as:
9904101418, 09904101418, 009904101418

Parts for Grove RT 890E, Figure 90014221:
Part Number 9904101418: DISC

Pos nr	Part number	Description	Weight in kg
1	9904101350	BEARING, PILOT	0.070
3	9904110094	CUPBEARING
4	9904110095	CONE,BEARING
5	9904110092	BEARING,ASSY.
6	9904110132	GEAR54T
7	9904106291	RING, BAFFLE
8	9904110091	RING,RETAINER	0.008
8	9904110093	RING,RETAINER
9	9904101207	RING. SNAP	0.012
10	9904110090	RETAINER	0.056
11	9904110089	SPRING,PISTON RETURN
12	9904105322	RETAINER
13	9904101411	RETAINER RING	0.07
14	9904101412	END PLATE	0.438
15	9904101418	DISC	0.14
16	9904101414	DISC, CLUTCH	0.108
17	90014211	CLUTCH PISTON & SEAL ASSY.	0.655
18	9904101416	RING, SEAL	0.740
19	9904101417	RING, SEAL	0.006
20	9904110435	SEAL	0.010
21	9274100258	RINGS	0.014
22	9904110439	CLUTCH HUB & DRUM ASSY.
23	9904110096	O-RING	0.010
24	9904110440	SHAFT & DRUM ASSY.
25	9904110186	SHAFT
26	9904110097	PLUG
27	7069000078	CONE	0.690
28	9904106194	CUP, BEARING	0.1
29	9904108795	SEGMENT	0.005
30	9904110104	O-RING	0.006
31	9904110099	SHIM .004
31	9904110100	SHIM .007
31	9904110101	SHIM .010
31	9904110102	SHIM .020
32	9904110105	O-RING	0.001
33	9904104055	PLUG	0.006
34	9904110103	CAP,BEARING
35	7950160050	LOCK WASHER 3/8" PEG	0.080
36	7115160850	BOLT HEX 3/R-16 HC X 1" - CR0 5	0.018
