Search for Crane Part number

(click on image to open PDF document)

Figures in which the part appears:
80018264 (Grove YB 4411 )
12079 (Grove YB 7722 )
Also known as:
1101274, 01101274, 001101274
Parts for Grove YB 4411, Figure 80018264:
Part Number 1101274: CIRCUIT BOARD
Pos nr Part number Description Weight in kg
1003152 ELEMENT, FILTER, OIL, SPINON, 1.86
1008737 HEAD, FILTER
90014168 KIT, REPAIR
90014747 VALVE ASSY. RELIEF @ 2500 PSI
6 195-104 F WASHER 3/8 REG ST-ZN 0.220
7 113-207 SCR, CAP, HH, 3/8NC X 1.00, G5
8 1003298 STRAP, TANK MOUNTING
9 113-248 CAP SCREW, 318NC X 2 3/4 HEX
10 131-52 NUT, SLL, 3/8NC, Z
11 192-21 L WASHER 3/8 REG MS 0.001
12 113-206 HHCS 3/8-16UNCX0.75|G5 0.001
13 218-1766 CONCTR,37S-STO,08,Z 0.072
14 1003144 VALVE ASSEMBLY - DUMP 0.586
15 218-5060 CONCTR, 37M-STO, 08-10, Z
16 80014232 VALVE ASSEMBLY - OUTRIGGER
17 1004886-011 HOSE ASSY, 1/2 X 11 5
18 80014191 ADAPTER ASSEMBLY - HARNESS
19 131-69 NUT, SLL, 5/16NC, Z
20 218-5211 PLUG, HEX-SKT, STO, 10, Z
21 218-5059 CONCTR, 37M-STO, 08, Z
22 113-132 CAP SCREW, 1/4NC X 1 3/4 HEX HEA
23 195-102 F WASHER 1/4 REG ST-ZN 3.700
24 1004971-018 HOSE ASSY, 1/4 X 18
25 218-5283 ELBOW, 90,37M-STO, 04-06, Z
26 1004885-012 HOSE ASSY, 3/8 X 12 0.240
27 192-20 WSHR, LOCK, 5/16, MED, Z
28 113-103 HHCS 5/16-18UNCX1.00 G5 0.012
29 610222 SWITCH|PRESSURE 850 PSI 0.340
30 218-980 ELBOW, 37M-37S, 06, Z
31 113-12 HHCS 1/4-20UNCX2.50 0.045
32 218-5103 DÈLETED
33 218-5106 ELBOW, 90,37M-STO, 08, Z
34 1101296 VALVE, PRIORITY FLOW CONTROL 2.882
35 218-5105 ELBOW, 90, 37M-STO, 06, Z
36 131-71 NUT, SLL, 1/4NC, Z
37 113-209 SCR, CAP, HH, 3/8NC X 1.50, G5
38 80018159 COVER, CIRCUIT BOARD,OUTRIGGER
40 195-513 WSHR, FLAT, 4*10, SAE, Z
41 1101274 CIRCUIT BOARD 0.720
44 7950080141 FLATWASHER 5/32" I.D. 0.006
45 1600302 HTA,M,CS,12,.083 0.001
46 218-5359 CONNECTOR, 04-08
47 218-5353 CONNECTOR, 12-08
48 704983 VALVE, BRAKE ACCUMULATOR CHARGIN 3.450
49 218-5120 ELBOW, 90,37M-STO, 08-12, Z
50 1004971-022 HOSE ASSY, 1/4 X 22 0.001
51 1600300 HTA,M,CS,24,.12 0.001
52 218-5478 TEE, 37M-375-37M
53 218-5089 CONCTR, 37M-STO, 04-06, Z USED W
54 1101408 VALVE ASSEMBLY-COMBO 1.455
55 702023-010 HOSE ASSY,1/4 X 10 0.165
56 702023-012 HOSE ASSY,1/4 X 12 0.185
57 702023-014 HOSE ASSY,1/4 X 14 0.195
58 1004971-014 HOSE ASSY
59 7429100008 WELL-NUT #8-32UNC 0.005
60 7950080350 LOCKWASHER 5/32" I.D.
61 218-5443 CONNECTOR, 04-06
62 1004698 VALVE, PRESSIJRE REDUCING
63 218-5057 CONCTR, 37M-STO, 06, Z
65 1600301 HTA,M,CS,24,.12 0.099
66 218-5276 ELBOW, 90 DEGREES
67 218-5228 CONNECTOR, 04-06
68 218-5070 CONCTR, 37M-STO, 08-12, Z
69 218-5173 ELBOW, 45, 37M-37S, 08, Z
71 1300498 FOUNDATION, VALVE BANK
72 218-476 ELBOW, 90 DEGREES
74 218-1085 ELBOW,90,37M,16-12,Z 0.386
75 1600309 HTA,S,12,.065,12.00,SS 0.001
76 1005427 ELBOW, 90 DEGREES (MODIFIED)
78 218-791 CONNECTOR, 37M-37F
79 218-344 NUT,37F,08,Z 0.030
80 1006674 ELBOW, 90 DEGREES SWIVEL
81 218-5053 CONCTR, 37M-STO, 04, Z
82 218-5170 ELBOW, 45 DEGREES
84 1101027 CONTROL VALVE 19.958
86 1003589 COUPLING, PRESSURE TEST 3/8
87 221-336 COUPLING,HEX,PF,04,Z 0.035
88 217-1080 NIPPLE,HEX,PM,04,Z 149.232
90 7506000019 GROMMET
91 1100578 FILTER, HYD OIL 2.760
92 1007543 VALVE ASSEMBLY - SOLENOID
93 113-410 SCR, CAP, HH, 1/2NC X 1.50, G5
94 195-106 CLAMP,HOSE,F,#10
95 131-10 HEXLOCKNUT 1/2-13UNC 0.009
96 218-845 TEE, 37M-37S-37M, 08, Z
97 218-5065 CONCTR, 37M-STO, 12-10, Z
98 217-1014 ELBOW, 90 DEGREES
* Selected parts are automatically added to your RFQ list *
1101274 Grove YB 7722 CIRCUIT BOARD
