Search for Crane Part number
Figures in which the part appears:
RT 540E (Grove RT 540E )
Also known as:
80044364, 080044364, 0080044364

CYLINDER ASSY, JACK (OUTRIGGER) - Part 80044364 for Grove cranes

Fits these models: Grove GMK, Grove RT 530E, Grove RT 540E

Figure RT 540E:

Part number Description Weight in kg
1482100000 FUSE, MAXI HOLDER
2212441 BRAKE DISK 28.300
315-9721 TURBOCHARGER
3201872 PUMP 40.820
3204649 PEDAL 6.500
3484240 CABLE DRUM CPL. TELESCOP CYLIND 19.800
4155799 SOLENOID-COIL 0.380
4157018 SEAL KIT 1.135
4157051 PROP.-RELIEF VALVE CPL 0.001
4157052 CONTROL VALVE HOISTING WINCH 14
4157080 SPRING CABLE REEL 19.800
4159013 CONTROLLER L1 CPL. 5.330
4159110250 STEP
4159110253 STRAP, MOUNTING
4159110254 STAAP, MOUNTING
4159110343 HANDLE, GRAB
4159110364 HANDLE, GRAB 1.440
4159810086 BRACKET, POWER FUSES
4165705 SET OF LININGS 7.900
4182372 BELT STRETCHER 1.660
4182382 PRESSURE AND TEMPERATURE SENSOR 0.001
6184100206 BRACKET, BATTERY HOLD-DOWN
6245101159 DOOR INSTALLATION - CAB
660810004 LUG WELD
6865148670 STUD
6970100151 TIRE + WHEEL ASSY
7064100004 12V BATTERY 26.600
7172100011 BOOT, POSITIVE TERMINAL VTE P/N 468L9V02 0.181
7246100350 CONTROL CABLE WITH LOCK HANDLE 5
7246100441 KIT - CABLE (BATTERIES)
7352100067 MODULE, CARRIER CONTROL 6
7352100069 MODULE, MASTER CONTROL 1.100
7447060405 TEE
7546802393 HOSE ASSY, 1 1/2"I.D. X 23" 2.590
7546803793 HOSE ASSY 3.080
7555104623 HOSE ASSY, .25 DIA 0.558
7555202101 HOSE ASSY
7555304402 HOSE ASSY
7555502761 HOSE ASSY
7555507491 HOSE ASSY, .75 DIA 2
7555603591 HOSE ASSY, 1.00 DIA 1.760
7561504850 3/4 HOSE ASSY
7561610261 1" HOSE ASSY
7910101496 TUBE ASSY,BRK TUBE TO TEE REAR
7910101569 TUBE ASSY,BRAKE TUBE REAR SHRT
7910101570 TUBE ASSY,BRAKE TUBE REAR LONG
7910101572 TUBE ASSY,BRAKE TUBE SHORT FRT
7910101639 TUBE ASSY, FRONT STEER
7910101640 TUBE ASSY, FRONT STEER
7910101671 TUBE ASSY SEL AXLE LO P2
795010050 WASHER, LOCK
80001701 SIDE ENGINE FOAM
80004322 CONTROLLER ASSY RIGHT HAND ARMREST 10
80004326 CONTROLLER ASSY LEFT HAND ARMREST 10
80004383 FOAM CENTER COVER
80005187 FOAM KIT-HOLST (M)
80014893 OUTRIGGER EXTENSION CYLINDER ASSY 51.071
80021340 CAP SCREW, 0.636
80023499 BATTERY CABLE RED 3/ 0.210
80024144 CURVED RADIATOR HOSE 0.783
80029622 PIN T/T LOCK CONTROL
80029763 PARK BRAKE | RANGE SHIFT VALVE 1.860
80030682 ANGLE
80031696 CURVED RADIATOR HOSE 0.39
80033011 BATTERY CABLE KIT|RT540E4 0.680
80033034 BATTERY BOX COVER
80033174 HA-RELAY PANEL|BATTERY BOX 0.065
80033489 PUMP ASS''Y|W/FLOW DIVIDER 5.450
80033704 BELLOWS 3.5 TO 3.0 X 6 LG 0.20
80033757 ALTERNATOR-24SI
80034166 FUSE PANEL
80041086 VALVE COVER INSTALLATION
80043367 HARNESS ITM ASSY 13.870
80044364 CYLINDER ASSY, JACK (OUTRIGGER) 68.3
80045046 ENGINE ASSEMBLY-CUMMINS QSB T4 1038.010
80047050 VALVE-BRAKE PEDAL 5.753
80049142 BOOM ASSEMBLY
80062020 ASSY, O/R FLOAT 23.500
80064599 GLASS | WINDSHIELD 10.872
80068618 CYLINDER ASSY, JACK (OUTRIGGER) 68.3
80070382 ENGINE CUMMINS 525
80071855 WINDOW-REAR|POSTERIORE 11.340
80078993 FILTER ASSY. HYD. RETURN 9.172
80089978 GLASS - RIGHT SIDE LOWER 3.030
80096777 CLAMP DOUBLE SADDLE 0.045
80099879 LIGHT 24V CAB 0.540
80111258 CYLINDER ASSEMBLY STEER 9
80111746 WORK LIGHT|REWORK-BOOM
90012925 VALVE, CART. PRESS. REDUCING 0.230
90023884 BELT DRIVE V-RIBBED 0.276
90026798 SWITCH ASSY 0.001
90038797 SWITCH ASSY. 0.184
9372103580 BARREL ASSY.
9372103581 ROD ASSY.
9372103582 HEAD ASSY.
C8391660 BEARING
C8491503 BEARING
C8926135 PIN, KING
C8989364 WASHER, THRUST
C8989365 RING, THRUST
* Selected parts are automatically added to your RFQ list *
80044364 Grove RT 540E CYLINDER ASSY, JACK (OUTRIGGER)
